Use of Nd magnets allows excellent responsiveness and high output in a compact size.
The rotor is evenly balanced to suppress mechanical vibrations.
Uses slotless coils which prevent cogging and allow smooth revolutions, even at low speeds.
Miniaturization and inclusion of a high pulse encoder means highly precise positioning is possible.
Lack of brush means no maintenance required
Distance between motor & driver extendable up to 10m (if using line driver specifications)

Parameter Name	Parameter Value
AC/DC	AC
Type	brushless
Protection class	maintenance-free
Configuration	permanent magnet slotless compact miniature
Cooling mechanism	air-cooled
Other characteristics	high-precision low-vibration low-speed
Power (W)	3 - 3
Torque (Nm)	0.0049 - 0.0049 0.0147 - 0.0147
Rotational speed (rpm)	6000 - 6000
Diameter (mm)	17 - 17
Operating temperature (°C)	0 - 40
