• For applications in industry, research and development
• For exact positioning and adjusting of optics, precision workpieces or other test objects

Technical data

• Load-bearing capacity 50 - 200 N
• Travel range 40 mm
• Resolution micrometer 10 µm
• Fine adjustment with micrometer 15 mm
• Height 57,5 mm

Benefits

• Fast adjustment for rough positioning
• Fine adjustment with side-mounted micrometer heads with 15 mm travel
• Precision ball bearings
• Hardened prism strips
• Made from sturdy steel
• Available with T-slots for easy mount of the test piece
• Available as light-measuring table
• Available with customized bore holes

Application

• For applications in industry, research and development
• For exact positioning and adjusting of optics, precision workpieces or other test objects

Parameter Name	Parameter Value
Orientation	XY
Type	manual
Number of axes	2-axis
Other characteristics	precision compact micrometer-driven for microscopes industrial focusing with ball bearing
Stroke (mm)	5 - 40
