Tarp Gear Motors Series w/Chrome Cover
DC right angle gear motor/DC worm gear motor/DC motor with worm gearbox/Tarp motors/DC motor with worm gearbox/DC gearmotor/DC geared motor/electric DC gear motor

MOTOR SPECS AND FEATURE:
· Epoxy sealed gearbox maintains lubrication
· 12V DC or 24V DC
· Rated Speed: 10RPM ~ 99RPM
· Max. Torque up to 270N.m
· Gear Ratios: 45:1, 60:1, 70:1, 90:1, 141:1
· Right Angle or Parallel Shaft design
· IP Class up to IP66
· 1~3 years warranty
· Power 600W(0.8HP ), 900W ( 1.2HP ) ,1125W (1.5HP ), 1500W(2.0HP ), 1875W(2.5HP)

Replaces Aero Power Plus, Donovan 1704878, 1800716, 1801965*, 1802061, 1802066, Roll-Rite #1030/1031, US Tarp #13732, 13957, 15275, 15938, 15364, 13655; Pulltarps 517-0906/517-0909; SHUR-CO 1703823; SuperWinch 90-33319/90-33295; Tarps and Beyond 1000XT/2000XT; Buyers Products 5543965/5541065, TSI Apache, Tomahawk, Enforcer.

12V Motor (Power Drive #'s 719527, 716527, 719520, 729520) Part No.: 90-33319
12V Motor (Power Drive #'s 719627, 716627, 716620, 729620) Part No.: 90-33295
24V Motor (Power Drive #'s 719537, 716537) Part No.: 90-33320
24V Motor (Power Drive #’s 719637, 719630, 719632) Part No.: 90-33318
12V Motor (Power Drive #’s 716727, 719727) Part No.: 90-33294

Parameter Name	Parameter Value
Motor type	DC AC permanent magnet brushless servomotor
Type	worm spur
Shaft orientation	right angle parallel-shaft
Shaft configuration	solid-shaft
Power (W)	100 - 500 10 - 50 50 - 100 0 - 10 500 - 1000 1000 - 2000
Voltage (V)	24 - 12
Torque (Nm)	0.5 - 1 1 - 5 5 - 10 10 - 20 20 - 50 0.2 - 0.5 50 - 100 0.1 - 0.2 0 - 0.1 100 - 200 200 - 500
Performance	high-torque high-power high-efficiency high-performance low-noise precision high load capacity
Product applications	for the food industry industrial for automation for robotics for mixers for agitators for doors for automatic distributors for medical equipment for trucks for welding machines cleaning machine for heavy-duty applications for agricultural applications for pharmaceutical applications for vehicles for lifting applications for conveyors door for pumps for tracks for machine tools for automobiles for packaging for power steering with encoder window for lawn-mowers for solar tracker for conveyor systems for electric vehicles for gates for the packaging industry for machines for robots
Certifications	CE ISO 9001 ISO 14001
Other characteristics	compact permanent magnet hollow-shaft 4-pole flange-mount
