Industrial Wireless Remote Control Switch Transmitter Receivers

Brand: LCC
Brand Name: LCC
Certification: CE
Place Of Origin: China
Function:8 single-speed buttons
Frequency: 315mhz
Transmitter Function: single-speed ,8 buttons
Transmitter Antenna: Inside
Receiver Antenna: Inside / optional external antenna
Housing:Reinforced nylon plastic
Distance: ≥ 100 meters / can be customized to 300 meters
Voltage: DC12V/DC24V/AC36V/AC220V/ AC380V

Detailed introduction: product performance indicators

*With 8 function buttons, 6 single speed buttons, 1 start/alarm, 1 total stop
* Control points up to 9
* With battery voltage warning device, it can cut off the circuit when the voltage is insufficient.
* Security key switch to prevent unauthorized use
* Internal functions can be set by computer interface
* Up/Down, East/West, South/North can be set to suppress each other
* The alternate button can be set to start, accelerate, self-lock, normal and other functions

1.Rugged transmitter button: The transmitter button can be pressed for 2 million times and is absolutely durable.

2.The receiver automatically searches for the transmitter channel function: automatic wireless pairing, replacing the transmitter vvithout professional equipment pairing.

3.Use advanced processor with multi-bit Hamming code: fast, high security, high précision and 100% error-ffee coding and decoding.

4.Extraordinary communication design, synchronous codée data transmission, with software to eliminate interférence, debugging, correction

Parameter Name	Parameter Value
Type	wireless
Control interface	with buttons
Number of buttons	8-button
Features	with emergency stop
Protection level	IP65 rugged
Product applications	industrial
Reach (mm)	0 - 100000
Temperature	Max.: 40 °C (104 °F)Min.: -35 °C (-31 °F)
Frequency (Hz)	315000000 - 315000000
