INDUSTRY/LOGISTICS – YOUR BENEFITS:
Cleaning the defined lanes in large industrial plants, production lines and notably logistic halls is no problem for the ADLATUS CR 700. Through simple definition of exclusion zones the robot will stay away from forbidden areas and thus reduce the potential risk of an accident.
Application planning of the robot can also be tailored to the individual requirements of an industrial or logistics facility.
DIMENSIONS:
WEIGHTmax. 300 kg
WIDTH755 mm
LENGTH1000 mm
HEIGHT980 mm
CLEANING UNIT:
SCRUBBING WIDTH700 mm
SQUEEGEE WIDTH710 mm
SCRUBBING PRESSURE<= 60 kg, continuously variable
BRUSH ROTATIONAL
VELOCITY<= 200 rpm, continuously variable
BRUSH TYPEStandard adapter for all common brushes and pads
BRUSH
DIAMETER2 x 355 mm
FRESH WATER
CAPACITY120 l with fully automatic dosing during cleaning, fully automated refills at
the service station
WASTE WATER
CAPACITY68 l with fully automatic draining at service station
CLEANSER
CAPACITY2 l with fully automatic dosing during cleaning
PERFORMANCE:
CLEANING
TIME3–5 h/battery charge, depending on battery options and cleaning intensity
CHARGING TIME3–8 h depending on battery and charging unit option
CLEANING SPEED0,3–max. 0,8 m/s, continuously variable
CLEANING AREA750–1500 m²/h, depending on settings and cleaning intensity
APPLICATION EXAMBLEWith an average operation of 4 hours, the CR 700 can clean approximately 4.000–5.000 m² per battery charge. Per day, including recharge of the battery, 8.000–10.000 m² are possible.
