Vibrating feeder phase angle controller R4FC

Vibrating feeder phase angle controller R4FC

Vibrating feeder phase angle controller R4FC

About


R4FC is a compact and easy-to-use phase angle controller. The maximum current is 4 A. Automatic input 0-10V or 4-20mA.

Application: Conveyor and assembly automation in packaging and dosing industry. Small linear vibrating feeder and vibratory bowl feeder

Max Output Current [A] -

5
Input Voltage [V] -

230
Vibration Frequency [Hz] -

50/100
Output Voltage [V] -

40-210
Stabilized vs Input Voltage -

Yes
Soft Start [s] -

0.2, 2
ON/OFF -

0-24V, Dry contact
Automatic Input PLC -

0-10V/4-20mA
Working Temperature -

-20/55°C (-4/131°F)
Enclosure -

Aluminum, Circuit, DIN35, DIN35 Circuit, Metal, Plastic, REM Aluminium
Protection Index [IP] -

IP00, IP20, IP55, IP65
Standard Conformity -

CE, EMC, Rohs



PARAMETERS

Parameter Name Parameter Value
Options
for vibrating feeders
