Reads all heads:
• Power: thermopiles, photodetectors and pyroelectrics
• Energy: thermopiles (in single shot mode), photodetectors and pyroelectrics

MEASURE FJ ENERGY LEVELS
Thanks to a unique digital method for suppressing the noise on the lower ranges

EXTERNAL TRIGGER
Synchronize your U-LINK to your pulsed laser or digital chopper

SERIAL COMMANDS
Serial commands are available on both versions to let you take full control

REAL-TIME STATISTICAL FUNCTIONS
Max, min, average, standard deviation, RMS and PTP stability

SYNCHRONIZE MULTIPLE CHANNELS
With the "SYNC. OUT" port, you can plug multiple U-LINK devices together and create a low-cost multi-channel system.

MAIN CONTROLS
Complete and easily navigable software interface with all the necessary options and tools:

• Connection: connect or disconnect your device.
• Controls: turn the turbo mode on or off, make a zero to remove the thermal offset, start the acquisition of the data and start the calculations of the statistics associated with this data.
• Startup config: save your measurements settings or load the settings associated with an already existing file.
• Help: get information about the PC-Gentec-EO software and read the user manual.
• Measure: configure the parameters related to your measurements.
• Display: set the desired number of digits and settings associated with the selected display.
• Acquisition: enter the parameters related to the acquisition of data.

MEASUREMENT PARAMETERS
The measure tab allows you to configure the parameters related to your measurements:

• Wavelength: enter the wavelength of your laser and the software will apply the appropriate correction factor on the measurements.

Parameter Name	Parameter Value
Bus	USB
Other characteristics	power
