• FUNCTIONS
- Direct connection to the computer’s USB port
- “Stand Alone” operating mode
- Modularity: several BPXs can be connected together to increase the number of probes used
- Increased immunity to negative environmental effects, whether of electrical origin or provoked by liquid and solid contaminants

• SOFTWARE
- TIS interface software is included in the BPX
- Possibility of indicating tolerance values
- Export of values to a .csv file

Max. perm. errors - At 20°C and relative humidity of ≤ 50 %
Digital output: ± (0,05 + 0,15 % of the measuring range)
Material - Housing: aluminium
Dimensions - 55 x 172 x 155 mm
Degree of protection - IP40
Particular characteristic(s) - At 20°C and relative humidity of ≤ 50 %:
Zero drift: ≤0,05 %/°C
Sensitivity drift: ≤0,05 %/°C
Acquisition time: 10 ms (between two consecutive measurements), 1 ms (timing window)
Time data transfer of digital serial output (USB): depends on the operating system of the computer
Weight - 1 kg
Power supply - 115 ÷ 230 V, 50 ÷ 60 Hz

Parameter Name	Parameter Value
Options	USB 2.0 electronic
Other characteristics	box
