Controller of temperature and standard signals, 3 relay outputs/SSR, 1 analogue mA/V, ON-OFF, PID with auto-tuning, program up to 6 sections with a timer, servo valve control, STB / LATCH function, manual mode, Ethernet, USB , RS485, MODBUS, MQTT, panel, wall and DIN rail enclosures

Technical details:
• control and supervision of temperature and other physical values (humidity, pressure, flow, level, velocity, etc.) converted into a standard electrical signal
• configurable architecture enabling using in many fields and applications (industrial, heating, food, energy, etc.)
• 2 universal measurement input(RTD, thermocouple TC, analog 0/4÷20mA, 0÷10V, 0÷60mV, 0÷2.5kΩ) with mathematical functions(diffrenence, sum, average, greater, or lesser of the measurements) available independenlty for displaying and controlling control/alarm output
• 2 function keys (F and SET) and digital input (BIN) for quick change of the controller operating mode, separately programmable: control start/stop, manual/automatic mode for outputs, step change of the SP setpoint , keypad lock, reset of errors and alarms STB (LATCH), unconditional preview of measured values from inputs 1 and 2.
• 3 control/alarm outputs of the on/off type (binary P/SSR) with independent functionalities and control algorithms(setpoints defined by the parameter or taken from the measurement input 1/2):
- ON-OFF with hysteresis (threshold characteristics for heating and cooling, band alarms within and out of range and with an offset for three-state control)

Parameter Name	Parameter Value
Display	with LED display
Type	PID programmable
Protection level	IP65 IP20 IP54 IP40
Other characteristics	panel-mount RS-485 universal auto-tuning DIN rail 4-20 mA Ethernet voltage output
Maximum temperature (°C)	-50 - 1800
