About
Host -
PC,PLC,MCU
Support motor -
2-phase stepper motor
The development environment -
VC C# Labviwe VB Linux Python
The power supply voltage -
DC12-48V
Microstepping -
0/256adjustable
Encoder type -
incremental、Single turn absolute 、multi turn absolute
Encoder resolution -
Optional 200-4000, software 4 times frequency processing (commonly used 1000)
Temp.Range -
-20℃-80℃
Maximum pulse frequency -
200K
Durability -
Over 20,000 hours
The input
IO function -
Emergency stop input, brake control, digital input/output, analog input, factory reset, 5V output
The input specifications -
Digital input voltage: 0-5V
Analog speed regulation input voltage: 0-3.3V
Emergency stop input voltage: 0-24V
Control mode -
Position mode, speed mode, PV mode, PP mode, PVT mode, analog speed regulation, analog positioning, synchronous positioning
Mode switching -
Specified instruction switching
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| AC/DC |
two-phase
|
| Type |
stepper
|
| Voltage (V) |
30 - 24
|
| Applications |
industrial
|
| Other characteristics |
|
| Torque (Nm) |
0.17 - 8.7
|
| Operating temperature (°C) |
-20 - 80
|
