High-precision movement, smooth movement, low noise, high speed
Unique square groove housing, increase the thermal capacity of the housing, extend the life of grease and so on. The selection of the housing material for ball-ink cast iron greatly improves the strength and performance of the housing, as well as the wide application at high/low temperatures. Square tail cover design, control screw does not spin. Advanced processing equipment and processing and assembly technology, is a guarantee of high product quality, advanced design concepts to create a strong impact resistance, high strength, low noise, long life, small volume of high-quality products.
The modular combination enriches the product mix variation, the spiral lift can be directly combined with the motor / gear box / special function accessories, integrated design, to provide customers with thousands of easy choices, specific parameters consult the local office.
Can be in accordance with customer requirements non-standard design, such as stainless steel housing and screw spiral lift, multi-head screw, high temperature, low temperature and other performance.
Accessories complete: dust cover, anti-tooth gap design, safety nut, acme screw, limit switch, overload clutch, potentiometer, encoder, brake, hand shaker, installation accessories, etc.

Parameter Name	Parameter Value
Type	trapezoidal screw
Other characteristics	high-performance safety nut worm gear for heavy loads flange with dual input shaft cast iron stainless steel
Stroke (mm)	50 - 4000
Speed (mm/s)	5 - 150
