Technical data
Product Features

Ergonomic design, thumb-operated

Single axis or multi-axis operation, spring return

Outdoor design, IP68S

Non-contacting Hall effect technology, high reliability, long service life

Redundant output option

Market Focus

Industrial remote controller

Control panel

Multi-function handle

Technical specifications

3.1 Mechanical data

Travel angle: ±25° (±2°)

Operating force: 1.6-3.5N

Maximum allowable force: 200N

Mechanical life: 5 million cycles

Weight: 20g

3.2 Electrical data

Supply voltage: 5.0±0.5vdc

Power current consumption: 10KΩ

Insulation resistance: >1000MΩ

EMC: 100V/M

3.3 Environmental data

Operating temperature: -25℃-+70℃

Storage temperature: -40℃-+85℃

Protection class : IP67 (only for electronics)

Parameter Name	Parameter Value
Technology	Hall effect compact single-axis analog 2-axis multi-axis
Applications	for remote control for CCTV applications
Other characteristics	IP67 fingertip thumbwheel USB CAN bus PWM multi-function
