The instrument cluster with 3 displays, one square 3.5” TFT colour display at the centre and two round TN displays, provides you everything to keep the vehicle data under control.

On request the bar graph segments of the round displays can be inverted (coloured segments). The design of the colour display can be customdesigned.

A variety of cluster options are available for you.

Casing:
Material: PBT-GB30, black Front side: chemical and UV resistant polyester foil Viewing area: low-reflective mineral glass
Aspect ratio:
4:3
Round Displays:
2x 26 bar graph segments, TN Technology, backlight: RGB colour LEDs, bar graph segments black
Warning lamps:
21 LEDs, 3 of them RGB colour LEDs, can be read clearly under direct sunlight
Buttons:
2 buttons with a clear tactile feedback
Electrical connection:
3x analogue inputs (custom configuration)
17x digital inputs (1x load resistor for pre-excitation of the alternator)
1x voltage supply measuring
2x FET output, maximum 500 mA
1x CAN ISO 11898 interface
Protocol:
CANopen, SAE J1939
Date and time:
Real Time Clock with internal battery backup
Voltage supply:
8…36 VDC
Ambient temperature:
-30°C…+85°C
Storage temperature:
-40°C…+85°C
Electrical connection:
Tyco Super Seal, 26 poles
Fixing:
metal clamp with screws
Protection class:
IP67 front, IP40 back (optionally IP65)
Vibration resistance:
EN 60068-2-64
Shock resistance:
EN 60068-2-27, EN 60068-2-29

Parameter Name	Parameter Value
Type	TFT color bar graph
Format	320 x 240
Applications	control
Other characteristics	electronic backlit CANopen IP65 IP67
