Each DSCP55 RTD Loop-Powered Converter provides a single channel of RTD input which is amplified, linearized and converted to a highlevel 4 to 20mA or 20 to 4mA output. Inputs may be connected by 2, 3, or 4 wires and measurement range may be configured by dip-switch.
RTD Input : Pt100 and Ni100 2-, 3- or 4-wire
Current Output : 4 to 20mA or 20 to 4mA
Loop Powered (5 to 30V DC)
Better than ±0.1% Accuracy
14-Bit Resolution
Output Overcurrent Protection
500mW Maximum Power Consumption
Dip-Switch Configuration
Cage Clamp Connectors
Hot Swappable
Expandable Power-Bus Connector on DIN Rail Guide
Compact 93.1 x 6.2 x 102.5mm PBT Black Case
Wide Operating Temperature Range : -20°C to 65°C
CE Compliant
RoHS Directive 2002/95/EC
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| Type |
|
| Applications |
for RTD sensors
|
| Other characteristics |
|
