Strain Wave Gear, is the use of metal flexibility, elastic mechanics and other principles, relying on flexible parts to produce elastic mechanical waves to transmit power and motion of a planetary gear transmission.

Features
REACH innovation team creates the RH tooth profile with the characteristics of continuous multi-arc-meshing surface. This RH tooth can adapt elastic deformation. Under heavy condition, more than 36% teeth meshed at the same time, which could significantly improve the performance of the harmonic reducer. Such as: noise, vibration, transmission accuracy, rigidity and lifetime, etc.

Advantages
Zero side clearance, small backlash design, back clearance less than 20 arc-sec.
With adoption of high-quality imported material and specially optimized heat treatment technology, its ser vice life is greatly improved.
Standardized connection size, good universality.
Low noise, low vibration, smooth operation, stable performance, safe and reliable.

Applications
Strain wave gears are widely used in robots, humanoid robots, aerospace, semiconductor manufacturing equipment, laser equipment, medical equipment, metal processing machinery, drone servo motor, communication equipment, optical equipment, etc.

Parameter Name	Parameter Value
Type	strain wave
Shaft orientation	coaxial
Applications	for servo motors for robots for automation for medical applications for machinery
Other characteristics	mechanical transmission high-quality for telecommunications equipment aeronautical parts electronic equipment laser
