AD-1531B
Digital Indicator for Strain Gauge Sensors

Suitable for load, pressure, torque or tension measurement plus more
Digital span calibration possible without using an actual load
Zero correction value can be backed up
Various output options available
Performs A/D conversion at 100 times per second

Options
AD4530-200 - Relay output
AD4530-030 - RS485
AD4530-040 - RS-232C input/output
AD4530-007 - D/A analog output
AD4530-237 - Relay output, RS485 and D/A analog output
AD4530-247 - Relay output, RS232C and D/A analog output
*The options above cannot be used at the same time.

Parameter Name	Parameter Value
Measured value	pressure, load, torque
Display	digital
Type	panel-mount portable
Other characteristics	4-20 mA RS-485 compact RS-232
Applications	for strain gauges
