Two phase, 48 steps per revolution
Key Features
Step angle (full step):
7.5 °
Length:
42 mm

Advantages
- COST EFFECTIVE POSITIONING DRIVE WITHOUT ENCODER
- HIGH POWER DENSITY
- VERY HIGH ACCELERATION
- EXTREMELY FAST CHANGE OF DIRECTION POSSIBLE
- LONG-LASTING
- WIDE OPERATING TEMPERATURE RANGE
- FULL-, HALF- AND MICRO-STEPPING OPERATION POSSIBLE
- EXTREMELY LOW ROTOR INERTIA

Parameter Name	Parameter Value
AC/DC	two-phase
Type	stepper
Configuration	aluminum
Other characteristics	high-power low-inertia
Intensity (A)	0.7 - 1.4
Torque (Nm)	0.085 - 0.085 0.152 - 0.152
Diameter (mm)	32 - 32
Operating temperature (°C)	-35 - 70
