About
The combination of our K27 spur gearheads with our brush DC coreless motors provides a single, factory-integrated solution for demanding, high-efficiency applications. Due to its spur compound geartrain arrangement, it provides the output in the same axis as of the motor. The K27 gearhead's inherent design results in overall better efficiency and lower noise which are the requirements for wide ranging applications like medical pumps, security and access and luxury goods.
Product Highlights
• For additional ratios, please download the specification pdf from the resources tab below
• High-precision performance at a competitive price point
• Reduction ratio of 6.2:1 to 2970:1
• Better power to weight ratio
• Sleeve and ball bearings options available
• Compact design
• Rated torque 0.4 Nm
• Customization as per application needs
Customization Available
• Custom shafts - flats, knurling, diameter, length
• Mechanical integration upon request (housing, front & rear flange, shaft)
• Special lubricants
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| Type |
spur
|
| Shaft orientation |
coaxial
|
| Torque (Nm) |
0.2 - 0.5
|
| Shaft configuration |
solid-shaft
|
| Number of stages |
multi-stage
|
| Performance |
|
| Applications |
for medical devices
|
| Other characteristics |
|
| Rotational speed (rpm) |
4000 - 4000
|
| Backlash (°) |
|
