KE600B Series Spindle Servo Drive
KE600B series high-performance spindle servo drive built-in position loop and servo positioning function. When used in the machine, it can realize closed-loop control of the spindle motor which has the encoder with the fast response and smooth speed feature.KE600B could be widely used in motor driving applications with a higher requirement on position control.

Features of KE600B Series Spindle Servo Drive
• Comprehensive parameter identification
With comprehensive parameter identification, simultaneously compatible with dynamic and static identifications for both synchronous motors and
asynchronous motors.
• Multi-motor switching
Built-in multiple motor parameters, supporting multi-motor switching.
• Modular design, compatible with various expansion cards
KE600B has superior expansion capability. Users can choose PG card, I/O expansion card, MODBUS communication card, injection molding
card, pulse expansion card, according to their actual needs.
• Fast dynamic response
Sensorless vector control, dynamic response time<20ms;
Close-loop vector control, dynamic response time<5ms.
• High-precision torque control
When close-loop vector control, the torque control accuracy achieving ±5%, easily responding to tension winding control.
• High start torque, and super low-frequency load-carrying capability
0.5Hz, 150% start torque (sensorless vector control asynchronous motors)0Hz, 200% startup torque (close-loop vector control asynchronous motors)

Parameter Name	Parameter Value
AC/DC	three-phase
Type	digital display vector control
Output signal	Modbus
Product applications	control spindle for machine tools for synchronous motor for asynchronous motors
Voltage (V)	220 - 660
Other characteristics	high-performance torque control built-in closed-loop low-voltage
Intensity (A)	3.7 - 1100
Power (W)	0 - 0 500 - 500
