Software functions - BLOB analysis (completeness monitoring)
BLOB analysis (presence control)
Dimension monitoring
Focus adjustment
Position determination
Camera resolution, horizontal - 752 px
Camera resolution, vertical - 480 px
Frame rate (images per second), max. - 50 pieces per second
Electronic shutter speed - 0.054 ... 20 ms
Camera type - Monochrome
Supply voltage UB - 18 ... 30 V, DC
Power consumption, max. - 8 W
Number of inputs/outputs selectable - 8 Piece(s)
Voltage type, outputs - DC
Switching voltage, outputs - Typ. UB / 0 V
Voltage type, inputs - DC
Switching voltage, inputs - Typ. UB / 0 V
Type - Ethernet, RS 232
Function - Process
Function - Process
Service
Function - Configuration interface
Data interface
Service interface
Type of connection - Connector
Designation on device - SERVICE
Thread size - M12
Function - Signal IN
Signal OUT
Voltage supply
Type of connection - Connector
Designation on device - PWR
Thread size - M12
Function - Data interface
Signal IN
Signal OUT
Type of connection - Connector
Designation on device - BUS OUT
Thread size - M12
Dimension (W x H x L) - 75 mm x 55 mm x 113 mm
Housing material - Metal
Lens cover material - Plastic
Net weight - 650 g

Parameter Name	Parameter Value
Applications	industrial
Technology	digital
Function	monitoring
Spectrum	monochrome
Sensor	CMOS
Interface	Ethernet
Other characteristics	smart IP67 high-performance
