1. 1100 lbs loading capacity
2. Lifting height (min/max): 14" - 38"
3. Table size: 32" length 20" width
4. Foot pump, manual push
5. With roller at the top for easy carring
6. 5" dia PU wheels, two rigid and two swivel with brake

Ideal for Many Applications
The simplicity and compact design of these carts make them suitable for lifting and transporting loads, order-picking, die handling and assembly operations. An ergonomic solution to lifting, positioning and transporting.

Reliable & Stable
Overload valve design prevents damage from misuse of the truck and reduces the overall maintenance cost. Each cylinder is equipped with an internal hydraulic velocity fuse. The heavy duty steel construction is engineered to hold up in harsh environments. Two rigid front casters and two rear swivel (with brake) increase maneuverability in tight areas.

Safety & Comfort
Safety stops minimize the risk of an empty deck from lowering while performing maintenance. Diminishes the amount of worker bending and lifting, which reduces risk of injury. Raise and lower the deck with mini pain and strain.

Parameter Name	Parameter Value
Technology	scissor
Operation	foot-operated
Type	mobile
Other characteristics	for order picking for die handling
Capacity	500 kg (1,102.3 lb)
Lowered height	36 cm (14 in)
Lifting height	96 cm (38 in)
Tray length	82 cm (32.28 in)
Tray width	50 cm (19.69 in)
Weight (kg)	104
