Designed as a “work station” to provide improved ergonomic conditions to ensure the health,
safety and comfort of the operator together with improved productivity

Plus:

• For evenly distributed load.
• Top platform with smooth surface.
• Max 20 cycles per hour, one shift a day.
• Self-lubricating bushings on pivot points.
• Upper and lower position by mechanical stops.

• Aluminium safety bar stops the descent of the platform in case of contact with obstructions
• Single acting hydraulic cylinders equipped with hose
safety valve, check valve and drainage.
• Low voltage “Hold-to-run” type control box
• Mechanical locks for safe servicing and maintenance
operations
• Removable lifting eye(s) to make easier handling and
installation
• Compliance with the Machinery Directive 2006/42CE
and Safety Requirements for lift tables EN1570-1.

Parameter Name	Parameter Value
Technology	scissor
Operation	hydraulic, electric
Type	stationary
Application	loading
Other characteristics	with safety barrier
Capacity	500 kg, 1,000 kg, 1,500 kg, 2,000 kg (1,102.3 lb)
Lifting height	Max.: 1,600 mm (63 in)Min.: 590 mm (23 in)
