High thermodynamic efficiency combined with a modular and flexible construction system for various applications

APPLICATIONS
Combined cycle systems
Biomass and waste to energy systems
Concentrated solar power systems
Heat recovery from industrial processes
Systems for the combined production of heat and power
Drivers for compressors, pumps, blowers and fans

Power range: up to 50MW
Temperature range: up to 540°C
Pressure range: 2,5 - 130 bara
Condensing/backpressure
Multiple extraction/admission
Modular design
Power gen/mechanical drive
Impulse/reaction turbine
Suitable for saturated steam
Packaged units (gear.LOS, auxiliares, etc.)

Parameter Name	Parameter Value
Type	saturated steam
Applications	for power generation mechanical drive for energy recovery for pumps
Other characteristics	combined-cycle reaction impulse
Rated power kW	Max.: 50,000 kW (67,981.06 hp)Min.: 100 kW (135.96 hp)
