Applications
Sensor monitoring
Motion control
Functional safety
Features
Sine/cosine encoder signal monitoring for SIL applications
Suitable for differential encoder signals of 1 Vpp (250 mV amplitude per line)
Suitable for single-ended signals (500 mV amplitude per line)
Monitor for input frequencies from 0 to 500 kHz
Verification of DC common mode range per signal line
Monitoring of Lissajous curve with min/max limits
Cable fracture detection
Source decoupling and overvoltage clamping per pin by external resistors
Single-failure-proof dual channel concept
Independent diagnostic outputs: signal OK message and signal error message
