SPECIFICATIONS
Working Pressure up to 250 bar
Torque up to 250.000 Nm
Angle of Rotation up to 1.080°
Special Angle of Rotation up to 1.500°
All sliding surfaces are surface-hardened
Rotary pistons can be run to their end stop positions and loaded
Rotation angle or end stop query possible via standard camshaft
Improved bearing efficiency with four-point bearing
Any intermediate rotation angle possible
Angular adjustment as standard
Improved end position cushioning (as standard)
State-of-the-art sealing technology
Stepless adjustment of the shaft position

Parameter Name	Parameter Value
Movement	rotary
Type	hydraulic
Configuration	double-acting
Material	stainless steel, aluminum, steel
Applications	for OEM industrial for medical applications food for dump truck for the automotive industry for robots guide for machine tools window linear for mechanical testing for clean rooms for mobile applications for demanding applications for ball valves for swing gates test turbine clamping for construction equipment for materials handling for process automation for lifting applications for the harshest off-road environments for agricultural machinery for wet environments for throttle valve for presses for butterfly valves for lifting for vehicles for sliding gates for harsh environments for ventilation systems chemistry security damper for solar trackers
Other characteristics	compact precision positioning high-force with proximity sensor helical high-performance end-of-stroke for integration ATEX high-tonnage for heavy loads control with integrated limit switch standard with integrated controller integrated guided horizontal transfer movement flange hollow-shaft custom high-efficiency right angle high-torque high load capacity wear-resistant with flange with linear motion units double stiffness mechanical small with potentiometer quarter-turn high-resistance
Force (N)	1567 - 34100
Torque (Nm)	200 - 200 0 - 0
Pressure	250 bar (3,625.9 psi)
Rotation angle	90 °, 180 °, 270 °, 360 °
