The robot is integrated in a box installed in front of the machine and picks workpieces from a pallet. The pallet is mounted on a 180 degree swing table to have a second pallet outside of working area to change the pallet while machine is working. The working area of robot is open and protected by laser curtain. Once operator enters the curtain the robot is slowed down and stopped.

A very flexible solution
for small batches mostly for sawed blank material
to replace operator who puts workpieces in and out only

In several SPINNER machines a Robot can be integrated inside the machine or on top of the machine directly. Those are flexible but performing solutions with shorter cycle time as the operator door doesn't need to be opened for loading and the operator is not limited by the robot. The process is quick and can be watched through normal front door.

A very flexible solution
for medium batches of all kind of worpieces
with several peripheric operations which can be integrated
Send us your demand with drawings that we can quote the most productive machining system for metal cutting and handling, from one source and under our full responsibility

SPINNER supplies most complex automated system for mass production in Automotive an other Industries to produce most complex and precise workpieces 24/7 with reliable processes.

Optimized for customers demand
with simultanious processes for cutting, loading, meassuring
with SPC documentation
Send us your demand with drawings that we can quote the most productive machining system for metal cutting and handling, from one source and under our full responsibility

Parameter Name	Parameter Value
Function	loading unloading
Applications	for the automotive industry
Other characteristics	high-flexibility
