RRU (Remote Radio Unit) is a new type of distributed coverage model,which concentrates large capacity macrocell base stations in the available central machine room. It uses optical fiber to pull the RF module in the base station to the remote RF unit, and put it on the site determined by the network planning, thus saving a large number of machine rooms needed in the conventional solution. At the same time, by using large capacity Acer station which supports a large number of remote optical fiber , it can realize the transformation between capacity and coverage.

Specification

-Volume: 553x450x256mm mm (height * width * depth)
-Weight: full 32kg
-Power consumption: 350W@220VAC
-Interface: 4*2.5G port
-Supporting 10Mbps Ethernet transparent interface channel
-Configuration: 2* carrier wave module / single machine2 carrier wave/ carrier wave module
-Power: 20W/ carrier wave 40W@O2
-Reception sensitivity: -113dBm
-Power: AC220V
-Protection level: IP65
-Environment condition
-Working temperature: -35℃～+55℃;
-Storage temperature: -40℃～+70℃;
-Relative humidity: ≤95％;
-UPS power supply and battery box (optical)
-Hanging- wall installation or rod install

Parameter Name	Parameter Value
Network	RF network fiber optic
