Features:
Higher power transmission capacity than wrapped Belts
Special cog design for enhanced flexibility and heat dissipation rate
Suitable for drives using smaller diameter pulleys and high RPM
Anti-static, oil & heat resistant
Maximum Belt linear speed (Classical section: up to 30 m/Sec, Wedge: up to 42 m/Sec, Narrow: up to 45 m/Sec)
Temperature range: -25°C to +100°C

Constructional Details:
Special fabric layer
Cushion rubber compound
Specially treated & stabilized polyester cord
Fibre-filled base compound
Moulded cogs for better flexibility

Parameter Name	Parameter Value
Type	toothed V
Material	rubber
Product applications	for machines for pumps for generator sets for blowers
Sector	industrial
Other characteristics	anti-static raw edge wrapped narrow oil-resistant heat-resistant
Width (mm)	10 - 25.4
Thickness	Min.: 6 mm (0.24 in)Max.: 23 mm (0.91 in)
Temperature	Min.: -25 °C (-13 °F)Max.: 100 °C (212 °F)
