Applications:
Point to Point Bridge / MMDS / Hotspot
Public Wireless
Wireless Video Systems
Features:
Superior Performance
Good appearance design
DC Short lightning protection
Outdoor antenna for public
Includes tilt and swivel mast mount brackets
RoHS Compliant
ELECTRICAL SPECIFICATION
V.S.W.R (Avg) - 1:2.5
Antenna Type - PIFA
Polarization - Vertical
Maximum Power - 500 Watts
Impedance - 50 Ohm
Antenna Design - High quality PIFA
Connector - SMA-Female
MECHANICAL SPECIFICATIONS
Length - 116mm
Width x Height - 26x23.5mm
Mount Style - Aliminum
Parts Material - Stainless steel screws
Mounting - Stainless Steel
Wind Survival - No
Storage Temperature - N/A
Operating Temperature - -40 to +80
Operating Humidity - -40 to +60
Storage Humidity - 10%~90% non-condesing
Safety, Emission and other - 5%~90% non-condensing
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| Network |
radio
|
| Type |
omnidirectional
|
| Other characteristics |
outdoor
|
| Applications |
for wireless networks
|
| Frequency (Hz) |
902000000 - 928000000
|
| Gain (dB) |
5 - 5
|
