Control Panel RCV CHS2002

With this control panel, the user can fully manage current rectifiers, dosing pumps, temperatures and so on, since it allows any of the data to be transferred through the company Ethernet. As with all other equipment made by R.C.V. S.r.l., it has been designed to be used in industry and provide the utmost reliability.

This is what makes it more than simply a PC: for all intents and purposes, it is a high-performance PLC boasting unquestionable versatility.
It can be adapted to any application to suit the customer’s specifications.



TECHNICAL SPECIFICATIONS

• Rectifier control over 2-wire CANopen network at speed of 1 Mbit.
• Full control of 45 current rectifiers.
• Management of dosing pumps with current sum in groups or per individual station.
• Thermoregulation monitoring and management (PWM-Pid-ON/OFF).
• Alarm log.
• Work printout management.
• 9 user password levels.
• PENTIUM 4 microprocessor.
• Software in LINUX environment.
• 10.4″ TFT LCD display.
• 10/100 Ethernet C&T 65550 output.
• 10 J-K thermocouple inputs.
• 10 PT100 inputs.
• 24 Optoisolated source-type digital inputs.
• 42 Optoisolated sink-type digital outputs.
• 4 Analogue inputs 0-10V dc.
• 4 PWM outputs with monitor powered +- 10V dc.
• Synchronous serial port for I/O.
• 10 user password levels.

Parameter Name	Parameter Value
Application	for pumps
Other characteristic	digital, TFT, microprocessor
