ATEX: optional

Versions:
low friction version
version with tie rods
version with metal scraper

Parameter Name	Parameter Value
Type	pneumatic
Technology	with piston rod
Configuration	double-acting
Norms	ISO 15552
Other characteristics	low-temperature explosion-proof
Stroke (mm)	0 - 2800
Force (N)	434 - 6623
Pressure	Min.: 2 bar (29 psi)Max.: 8 bar (116 psi)
Rod diameter	Min.: 32 mm (1 in)Max.: 125 mm (5 in)
Speed (mm/s)	84000 - 10303000
Ambient temperature	Min.: -20 °C (-4 °F)Max.: 80 °C (176 °F)
