Component Parts and Materials
1 Steel AISI 304 Nut
2 Steel AISI 316 Piston rod
3 Polyurethane Rod seal
4 Steel AISI 304 Front cover
5 Steel AISI 304 Nut
6 Sintered bronze Bearing
7 NBR O-RING Seals
8 Neoprene Bumper
9 Brass Piston
10 Polyurethane Piston seal
11 Plastoferrite Magnet
12 Steel AISI 304 Mini cylinder shape body
13 Steel AISI 304 Back cover

Fluids
Filtered and lubricated compressed air as well as non lubricated air.

Functioning
Double-acting magnetic.
Double-acting without magnet.

Parameter Name	Parameter Value
Type	pneumatic
Technology	magnetic piston
Configuration	double-acting
Material	stainless steel, brass
Other characteristics	mini
Stroke (mm)	10 - 320
Pressure	Max.: 10 bar (145 psi)Min.: 2 bar (29 psi)
Rod diameter	16 mm, 20 mm, 25 mm (1 in)
Ambient temperature	Max.: 80 °C (176 °F)Min.: -20 °C (-4 °F)
