About
Enable high thrusts to be achieved in restricted space
Neat, clean appearance
One-piece body construction
Medium: - Compressed Air
Port size: - G1/8
Cylinder diameter: - 32 mm
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| Type |
pneumatic
|
| Technology |
with piston rod
|
| Configuration |
single-acting
|
| Material |
stainless steel, anodized aluminum
|
| Applications |
clamping
|
| Other characteristics |
compact
|
| Stroke (mm) |
25 - 25
|
| Force (N) |
445 - 445
|
| Pressure |
Max.: 10 bar (145 psi)Min.: 2 bar (29 psi)
|
| Ambient temperature |
Max.: 70 °C (158 °F)Min.: -10 °C (14 °F)
|
