About
DGRHTV10-39 The planetary roller screw Electric Cylinder the maximum rated speed reaches 17.5-35 mm/s even more, effective stroke 10-3000mm, maximum rated thrust 72-144KN even more,parallel type.
Features
Application
The Planetary Roller Electric Cylinder can withstand heavy loads for thousands of hours in harsh environments, making it an ideal choice for applications requiring continuous duty.
Lubrication
The lubrication method of planetary roller electric cylinder is generally the same as that of gears and bearings, and oil lubrication or grease lubrication can be selected based on actual application conditions. If not specified specifically. We can also recommend more suitable lubrication methods based on the actual working environment requirements of customers.
We are practitioners of Planetary Roller Screw Electric Cylinder manufacturing, practicing the spirit of craftsmanship and striving to build and establish industry benchmarks.
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| Type |
electric
|
| Technology |
planetary roller screw
|
| Material |
steel
|
| Protection class |
for harsh environments
|
| Other characteristics |
|
| Stroke (mm) |
10 - 3000
|
| Force (N) |
72 - 144
|
| Torque (Nm) |
|
| Motor power |
3 kW (4 hp)
|
| Speed (mm/s) |
17.5 - 35
|
| Repeatability (mm) |
0.05 - 0.05
|
