Complete range of multi-purpose planetary gears. Input can be via electric motor, hydraulic motor, air motor or bare input shaft, be it a splined or parallel keyed input shaft.

jbj Techniques can accommodate gearbox inputs to suit your own bespoke requirements, even for a one off!

Designed for rugged use and dependability. The gear case is made of nodular iron, whilst the planet carriers, are made out of steel or high-tensile nodular iron. All gearing is heat treated with full addendum modification, as well as lead and profile modification in order to obtain the best performance, efficiency, and low-vibration. The close tolerances in all of the gears and floating planet carriers allow the load to be evenly shared by all the components.

Features of the range:
» 32 sizes.
» Output torque up to 1.000,000 Nm.
» Transmissible power up to and above 550 kW.
» Ratios going from 3 to over 3000:1
» High efficiency, up to 98.5% per stage.
» Modular structure.
» Full planetary in-line and combined Gleason-planetary right-angle units available.
» 1 to 4 reduction stages, on request 5 stages.
» Optional spring applied-hydraulically released multi-disc brake.
» Flange, foot and shaft mounting versions, bare shaft output available.
» Output shafts include solid keyed, solid splined, hollow splined or for shrink disc mounting.
» Vast range of accessories for the low speed shaft: drive flange, splined bushing, slew pinion, splined rod, shrink disc, torque arm.
» Broad selection of input adaptors to suit standard electric motors both IEC and NEMA, air and hydraulic motors, male input shafts for mechanical linkages.

Full technical specification catalogue available.

#DriveLineHarmony

Parameter Name	Parameter Value
Type	planetary
Shaft orientation	coaxial right angle
Torque (Nm)	10000 - 10000
Shaft configuration	hollow-shaft vertical output shaft solid-shaft
Number of stages	single-stage two-stage four-stage three-stage
Performance	high-performance high-torque high-efficiency for heavy loads high-power
Applications	for agitators for heavy-duty applications for marine applications for machinery for conveyors for railway vehicles for construction vehicles for industrial vehicles for roller mills transmission for mining equipment for wind turbine for the chemical industry for food industry machinery
Other characteristics	industrial with flange flange custom rugged motor mechanical transmission modular
Power (W)	550000 - 550000
