» High efficiency
» Output shaft with double ball bearings
» All stages have straight toothing
Gear ratio - 6.25 : 1
Number of stages:1
Nominal output torque Ncm:70
Max. efficiency - %:90
Max. axial load - N:150
Max. radial load - N:230
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| Type |
planetary
|
| Shaft orientation |
coaxial
|
| Torque (Nm) |
1 - 5
|
| Performance |
high-power
|
| Applications |
for electrical drives
|
| Other characteristics |
compact
|
