High Modularity

Modular design with compact subgroups, for easy ratio replacement (up to 4 reduction stages).
High Versatility

6 sizes with 4 input and 4 output configurations.
2 output support connections:
SM (standard)
SMR (high load)
3 options of mounting positions:
Direct
FM (foot-mounting)
FL (flange-mounting)
High Performances

Max input power 200 kW.
Max torque 25000 Nm.
Ratios up to 3657/1.
High Reliability

Sturdy cast iron housing for heavy duty applications.
High resistant gears made in top quality steel.
Largely proportioned bearings.
High quality sealing for improved leaking prevention.

Parameter Name	Parameter Value
Type	planetary
Shaft orientation	coaxial
Torque (Nm)	10000 - 10000
Performance	for heavy loads
Applications	for heavy-duty applications
Power (W)	200000 - 200000
