Features Custom Features

Configuration: Inline
Maximum Output Torque: 120Nm
Number of Drive Stages: 1, 2 or 3
Dimensions - W x D x H: Ø x Length
32 - 81 x 52 - 170mm
Weight: 0.16 - 3.2Kg
Maximum Shaft Diameter: 19mm
Construction: Aluminium
Lubrication: Grease (sealed for life)

Internal Declutch: No
Mounting Options: Yes
Gear Material: Steel or Delrin®
Hollow Shaft Option: No
Ratio: 4:1-300:1

Parameter Name	Parameter Value
Type	planetary
Shaft orientation	coaxial
Torque (Nm)	100 - 200
Other characteristics	for DC motors
