Our PMAC motors, designed and developed by our motor engineers are manufactured in our plants in Modena Italy with the highest quality components coming from worldwide known and extremely reliable suppliers.

Our PMAC Brushless Motors are synchronous motors with permanent rare earth magnets mounted on the rotor developed for taction, lifting, steering applications that require constant torque even at extremely low speed.

The above mentioned feature is achieved by the synchronism betweend the motor's rotor and stator, an integrated sensor (SinCos, Resolver or Hall cell Incremental) provides the exact angular position to the electronic controller which manages this information and maintains the synchronism on torque’s variations

Energy saving is the main goal for the development and the conversion to the PMAC motor technology; due to its versatility, and superior building quality our PMAC motors are designed to extend batteries duty cycles and life.

- Average efficiency 93-95%
– Max torque up to 5 times more than the nominal
– Compact dimensions, thanks to high power density
– Lower thermal heating
– Longer battery duty cycle
– Absence of friction components

Available upon request:
- Extended shafts for encoders
– Wide range of thermal sensors
– Sin/cos sensor, resolver, incremental hall cell encoder
- Custom shafts,flanges, frames
- Custom terminal boxes and mounting feet

Our PMS motors are manufactured in conformity with norms IEC BN B5/BN B14 56-100, with aluminum or steel housings.

Our PMS motors are manufactured in conformity with norms EN 60034, IEC 60034 and REACH 81907/2009/CE, RoHS (95/2002/CE + 65/2011/CE) on environmental protection.

Parameter Name	Parameter Value
AC/DC	AC
Type	synchronous
Configuration	permanent magnet aluminum compact
Applications	traction for lifting applications for power steering
Other characteristics	custom high-efficiency low-noise high-power low-speed
Power (W)	400 - 400 0 - 0
Torque (Nm)	1 - 100
Rotational speed (rpm)	100 - 5000
