Technical specification
1. Light source: semiconductor laser
2. Particle size range: 0.8um~600um (depending on different sensors)
3. Sensitivity: 0.8um (ISO4402) or 3um (c) (GB/T18854, ISO11171)
4. Detection channel: 8 channels arbitrarily set the particle size
5. Resolution: better than 10% (GB/T18854, ISO11171)
6. Repeatability: RSD<2%
7. Viscosity range: up to 350cst
8. Sampling volume: 0.2~1000ml
9. Sampling accuracy: better than ±0.5%
10. Sampling speed: 5mL/min ~80mL/min
11. Maximum vacuum of the pressure cabin: 0.08MPa
12. Maximum positive pressure of the air chamber: 0.8MPa
13. Power supply: AC220V±10%, 50Hz
14. Net weight: 20kg

Parameter Name	Parameter Value
Type	particle
Display	analog
Technology	laser
Applications	oil for hydraulic fluids for automotive fluids for gasoline
