Materials:
cabinet profile is grey powdercoated, drawer profile cold rolled steel uncoated for welding

Features:
Delrin* encased steel roller bearings

Standard Hole/Slot for weld jig alignment

Specifications:
Standard Mounting Tab system allows for quick installation and flexibility in drawer slide model selection

cabinet profile is powdercoated, drawer profile is uncoated (raw) to allow welding by installer.

openings for the mounting tabs are 12mm x 12mm

front and rear openings are on the same level

mounting strips can be identical front, back, left and right

standard thickness for the mounting hat is 1.5mm (16 gauge) steel with option for 1.9mm (14 gauge) steel available

double-sided captive profile

self-closing

Parameter Name	Parameter Value
Extension	partial-extension, telescopic
Type	roller
Other characteristics	bottom-mount steel double
