About
Colour touchscreen display
USB ‘plug & play’
6 universal Inputs
96MB non-volatile flash memory
125ms parallel sampling
Compact Flash
Modbus RTU
Ethernet TCP/IP
Web server
AMS2750F is forcing aerospace suppliers to adopt rigorous procedures for furnace maintenance. The AeroDAQ is designed to help you comply with Aerospace industry standards.
Description
Thermocouple life monitoring
The 6180 AeroDAQ provides thermocouple life monitoring functionality based on AMS2750F, Sections 3.1.5 and 3.1.5.3. Both thermocouple Uses and Days remaining are accounted for to help assure that thermocouples are not used beyond their maximum life as per AMS2750F.
Automated scheduling
Using a furnace when it has exceeded the allowable period for calibration, TUS (Thermal Uniformity Survey), or SAT (System Accuracy Test) can result in audit noncompliance, and monetary loss.
The 6180 AeroDAQ provides notification of due dates for:
Calibration
TUS
SAT
Reporting capability
Your success depends not only on your skill in managing heat treatment processes, but also in proving that your process conforms to your customers’ specifications and the standards of your auditing bodies.
The reporting package that accompanies the 6180 AeroDAQ provides a standard batch reporting functionality including:
Customer information
Batch information
Trending
Alarm summary
The 6180 AeroDAQ reporting package can be easily customized to meet your specific requirements, transforming securely archived data into batch information critical to you and your customers.
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| Type |
paperless
|
| Measured physical value |
universal
|
| Applications |
alarm
|
| Other characteristics |
|
