Special version - Heating
Integrated laser alignment aid
Not influenced by reflective surfaces
Operation of parallel light axes
Transmission frequency - F4
Usable opening angle transmitter - 1 °
Supply voltage UB - 18 ... 30 V, DC
Number of digital switching inputs - 1 Piece(s)
Number of digital switching outputs - 1 Piece(s)
Type - EtherCAT link down 5 ms, EtherCAT Safety-over-EtherCAT (FSoE)
Number of connections - 2 Piece(s)
Type of connection - Connector
Designation on device - POWER
Thread size - M12
Type - Male
No. of pins - 5 -pin
Encoding - A-coded
Type of connection - Connector
Designation on device - BUS
Thread size - M12
Type - Female
No. of pins - 4 -pin
Encoding - D-coded
Dimension (W x H x L) - 100 mm x 156 mm x 99.5 mm
Housing material - Metal
Net weight - 1,422 g
Type of display - Bar graph
LED
Type of configuration -
Ambient temperature, operation - -35 ... 50 °C
Ambient temperature, storage - -35 ... 70 °C
Certifications - c UL US
Test procedure for EMC in accordance with standard - EN 1000-6-4
EN 61000-6-2
Test procedure for noise in accordance with standard - EN 60068-2-64
Test procedure for oscillation in accordance with standard - EN 60068-2-6
Test procedure for shock in accordance with standard - EN 60068-2-27
