Technical data
Product Features

Ergonomic design, hand-operated

Single axis or multi-axis operation,

friction brake at Y axis

Robust joystick, applicable for severe environment

Non-contacting hall Effect technology, high reliability, long service life

Configured with 2A@30Vdc micro switches

J1939 and CANOpen options

Varieties of multi-function grips available

Market Focus

electro-hydraulic control

industry automation control

This product can be applied in Agriculturre machinery also.

3. Technical Specifications

3.1 Mechanical Data

Travel Angle: ±20°

Operating Force*: 10~20N (spring return) ,

1.7~2.2Nm ( Friction hold)

Maximum Allowable Force: 300N

Service Life: 5 million cycles (spring return) ,

1 million cycles (Friction hold)

Weight: 850g（no handle fitted）

*Measured 103mm from pivot point.

3.2 Electrical Data

3.2.1 Analog/Hall voltage output

Supply Voltage: 5.0 ± 0.5Vdc or 9～36Vdc

Current consumption: 10KΩ

Insulation Resistance: >1000MΩ

EMC: 100V/m

Parameter Name	Parameter Value
Technology	Hall effect analog 2-axis compact multi-axis micro-switch hydraulic digital
Applications	for remote control for utility vehicles for off-highway vehicle
Other characteristics	USB with buttons CANopen rugged multifunction with interlock system panel-mount IP65 ProfiNet with switch with integrated control handle lift-lock with dead-man switch CAN bus with armrest PWM SAE J1939 spring-return force sensor with ball handle acceleration programmable
