PALLET HANDLING
TURNTABLE

Structure
       S235JR steel, powder coated RAL 9006 / RAL 1021.
Security side cover
       Optional, powder coated RAL 1021.
Height
       350 mm up to 600 mm TOR (top-of-roller) with +50 mm adjustment.
Roller pitch
       150 mm.
Roller Conveyor Gearmotor Drive
       SEW Gearmotor 0.37kW / 230/400V / 50Hz / 3 phase rated voltage, IP55, CE.
       SEW Gearmotor 0.37kW / 230/460V / 60Hz / 3 phase rated voltage, IP55, UR.
       SEW Gearmotor 0.37kW / 330/575V / 60Hz / 3 phase rated voltage, IP55, CSA.
Roller Conveyor Speed
       12 m/min / 39.37 ft/min.
Turntable Rotation Gearmotor Drive
       SEW Gearmotor 0.37kW / 230/400V / 50Hz / 3 phase rated voltage, IP55, CE.
       SEW Gearmotor 0.37kW / 230/460V / 60Hz / 3 phase rated voltage, IP55, UR.
       SEW Gearmotor 0.37kW / 330/575V / 60Hz / 3 phase rated voltage, IP55, CSA.
Turntable Rotation Speed
       2,6 rot/min.
Direction
       CW and CCW.
Stop Position
       -90° to +90°.
Installation
       Horizontal application only.
Sensors
       Supports compatible with Sick IME18 included. Sensors included.
Electrical Connections
       Prewired roller motor and sensors to junction box.
Operating Temp.
       5°C to 50°C / 41°F to 122°F.

Parameter Name	Parameter Value
Operation	motor-driven
Configuration	horizontal
Other characteristics	rotating with roller conveyor
Diameter (mm)	2168 - 2368
