FusionSight® is a world-first digital night and day vision enhancer providing smart fusion for threat and target accurate detection. This all-in-one device combines three viewing modes - color low light, thermal and smart fusion. Especially adapted to military requirements, this reliable device drastically improves the detections of threat and targets for quick or long-lasting surveillance missions.
Offering considerable support, either on the field or Police and Homeland Security missions, this state-of-the-art color imaging sensor is able to take pictures in extremely low light condition (~10 mlx) whereas its high-resolution thermal sensor is capable of detecting human presence in any night conditions (up to night 5). In addition, FusionSight®’s embedded real-time image processing automatically selects the key information to enhance from each sensor. It enables picture snapshots as well as live streaming on multiple devices for long-lasting operations.
Easy-to-use, it is thus an efficient and reliable device for the detection of camouflaged enemies as well as casualties or missing persons under wreckage, during search and rescue missions.

TECHNICAL CHARACTERISTICS

• Thermal sensor: UC (8-12μm); 640 x 480 @17μm

• Visible sensor: CMOS low light colour; 1280 x 1024p

• Display: OLED Full HD; 1280 x 1024

• Night FOV: W: 32° / N: 8°

• Day FOV: W: 29° / N: 7.25°

• Autonomy: 7 hours

• Weight: 990 g

• Embedded sensors: Compass; 9-axes IMU and GPS

• Embedded functions: Image recording; up and down wireless communication

• Video output: 25Hz HD colour

Parameter Name	Parameter Value
Applications	for military applications
Technology	digital
Function	surveillance security detection
Sensor	CMOS
Resolution level	full HD, 1280 x 1024
Other characteristics	day/night low light monocular
