About
BarnMini-07 is a 4-channel CWDM mux that can be used e.g. for transportation of 4x 3G-SDI for UHD transmission over different mediums. This is a compact, efficient and affordable mux and fits alongside all other BarnMinis into the BTF-MINI-16 frame. BarnMini-07 saves you both rack space and money. For growing up to 8 channels, BarnMini-07 is available in two versions: BarnMini-07-2935 (1290-1350nm) and BarnMini-07-3743 (1370-1430nm + upgrade port); both units can be casceded.
Optical ports
LC/PC connectors
BarnMini-07-2935: 1290nm – 1350nm according to ITU-T G694.2
BarnMini-07-3743: 1370nm – 1430nm according to ITU-T G694.2
Channel clear passband +/-6,5nm
Insertion Loss 45dB
Polarisation dependant loss 0,02dB
Directivity >50dB
Return loss >45dB
Polarisation Mode Dispersion <0,2ps
Physical size
92mm x 98mm x 22mm
200g
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| Type |
module
|
| Options |
optical
|
