Component Parts and Materials
1 Zinc-plated steel Nut
2 Steel AISI 303 Piston rod
3 Polyurethane Rod seal
4 Anodised aluminium Front cover
5 Zinc-plated steel Nut
6 Sintered bronze Bearing
7 NBR O-RING Seals
8 Neoprene Bumper
9 Brass Piston
10 Polyurethane Piston seal
11 Bonded Ferrite Magnet
12 Stanless Steel AISI 304 Mini cylinder shape body
13 Anodised aluminium Back cover

Fluids
Filtered and lubricated compressed air as well as non lubricated air.

Functioning
Single acting magnetic or non-magnetic.
Double acting single or double end rod,
magnetic or non-magnetic, cushioned or
non-cushioned.

Parameter Name	Parameter Value
Type	pneumatic
Technology	magnetic piston with through rod
Configuration	double-acting
Material	steel, brass
Norms	ISO
Other characteristics	miniature
Stroke (mm)	10 - 320
Pressure	Max.: 10 bar (145 psi)Min.: 1 bar (14.5 psi)
Rod diameter	16 mm, 20 mm, 25 mm (1 in)
Ambient temperature	Max.: 80 °C (176 °F)Min.: -20 °C (-4 °F)
