- High-Performance 32 Bit ARM® Cortex®
- 3 analog Inputs 0 to 30 VDC, 12 bit ADC
- Event Counter Input 25 kHz
- Pulse and Frequency Counter Input 40µs
- 4 Solid-State Power Outputs up to 1.5 A
- 1 Power PWM Output 16 Bit 1 Hz to 25 kHz
- CAN 2.0A/B and SAE J1939 Interface
- CANopen® Interface (Open Source)
- Comprehensive Fail Safe Functions
- Programmable Status LED
- TTL-232 3.3V Interface
- Intuitive graphical Programming Capability
- Open Source Programming
- ARDUINO® Programming
- Wide Operating Voltage Range 7 to 32 VDC
- Wide Operating Temp. Range -40 to +70°C
- Vibration resistant and rugged Sealing
- CE, UL und ECE-R10 certified
- Engineered and manufactured in Germany
- Dimensions (LxWxH): 60x45x15mm
- Weight: 50g

Parameter Name	Parameter Value
Type	mini
Input/output	analog inputs, digital input, digital outputs, analog outputs
Network	CAN bus
Other characteristics	rugged
