M Series Driver for 2-Phase Hybrid stepper MOTOR
l General Description
M series drivers are high performance microstepping driver based on the most advanced technology in the world today. They are suitable for driving any 2-phase & 4-phase hybrid stepper. By using advanced bipolar constant current chopping technique, they can output more speed & power from the same motor, compared with traditional technologies such as L/R drivers. Its patented current control technology allows coil currents to be accurately control, with much less current ripple & motor heating.
M415B-FL
Features
² High performance, Low cost
² Supply voltage to +40VDC, peak current to 1.5A
² Automatic idle-current reduction.
² Microstep resulations up to 12,800 steps/rev.
² Optically isolated signal I/O
² Inaudible 20KHz chopping frequency, highest respond frequency up to 100KHz.
....
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| Motor type |
|
| Other characteristics |
